充電電池
鎳氫電池
| Ni-MH Rechargeable Battery | SIZE | NOMINAL VOLTAGE | NOMINAL | DIMENSIONS (mm) | WEIGHT | STANDARD CHARGE | QUICK CHARGE |
|---|---|---|---|---|---|---|---|
| (V) | (mAh) | (v) | (g) | ||||
| MR9000D | D | 1.2 V | 9000 mAh | 32.2 (D) x 61.3 (H) | 160 | 900 mAh x15-16 hrs | 2700 mA x 5 hrs |
| MR4500C | C | 1.2 V | 4500 mAh | 25.3 (D) x 49.0 (H) | 83 | 450 mAh x15-16 hrs | 1050 mA x 5 hrs |
| MR3300C | C | 1.2 V | 3300 mAh | 25.3 (D) x 49.0 (H) | 77 | 330 mAh x15-16 hrs | 990 mA x 5 hrs |
| MR3000SC | SC | 1.2 V | 3000 mAh | 22.1 (D) x 42.0 (H) | 53 | 300 mAh x15-16 hrs | 900 mA x 5 hrs |
| MR1800AS | 4/5A | 1.2 V | 1800 mAh | 16.2 (D) x 42.1 (H) | 37 | 180 mAh x15-16 hrs | 1800 mA x 1.5 hrs |
| MR600AAS | 2/3A | 1.2 V | 600 mAh | 13.9 (D) x 28.1 (H) | 13 | 60 mAh x15-16 hrs | 600 mA x 1.5 hrs |
| MR2500AA | AA | 1.2 V | 2500 mAh | 14.2 (D) x 50.5 (H) | 30 | 250 mAh x15-16 hrs | 750 mA x 5 hrs |
| MR2400AA | AA | 1.2 V | 2400 mAh | 14.2 (D) x 50.5 (H) | 29.5 | 240 mAh x15-16 hrs | 720 mA x5 hrs |
| MR2200AA | AA | 1.2 V | 2200 mAh | 14.2 (D) x 50.5 (H) | 29 | 220 mAh x15-16 hrs | 660 mA x 5 hrs |
| MR2000AA | AA | 1.2 V | 2000 mAh | 14.2 (D) x 50.5 (H) | 28.5 | 200 mAh x15-16 hrs | 600mA x 5 hrs |
| MR1800AA | AA | 1.2 V | 1800 mAh | 14.2 (D) x 50.5(H) | 28 | 180 mAh x15-16 hrs | 540 mA x 5 hrs |
| MR1600AA | AA | 1.2 V | 1600 mAh | 14.0 (D) x 50.0 (H) | 25.5 | 160 mAh x15-16 hrs | 480mA x 5 hrs |
| MR1300AA | AA | 1.2 V | 1300 mAh | 14.0 (D) x 50.0 (H) | 24 | 130 mAh x15-16 hrs | 1300 mA x 1.5 hrs |
| MR600AAA | AAA | 1.2 V | 600 mAh | 10.1 (D) x44.5 (H) | 12 | 60 mAh x15-16 hrs | 600 mA x 1.5 hrs |
| MR700AAA | AAA | 1.2 V | 700 mAh | 10.1 (D) x44.5 (H) | 12.5 | 75 mAh x15-16 hrs | 210 mA x5 hrs |
| MR800AAA | AAA | 1.2 V | 800 mAh | 10.1 (D) x44.5 (H) | 12 | 80 mAh x15-16 hrs | 240mA x 5 hrs |
| Ni-MH6F22 | 6F22 | 1.2 V | 1800 mAh | 16.5 (W)x25.6(L)x48.0(H) | 39 | 18 mAh x10 hrs | 36mAh x6 hrs |
| Ni-MH Rechargeable Button Cell | NOMINAL VOLTAGE | NOMINAL | DIMENSIONS (mm) | HEIGHT (mm) | WEIGHT | CHARGE CURRENT | QUICK CHARGE | |
|---|---|---|---|---|---|---|---|---|
| (V) | (mAh) | +/- | ||||||
| 0.2mm | -0.4mm | (g) | (mA) | |||||
 | H320BC | 1.2 V | 300 | 25.2 | 8.7 | 13.3 | 33 | 9.9~16.5 |
 | h160BC | 1.2 V | 280 | 25.2 | 7.6 | 12 | 28 | 8.4~14.0 |
 | H120BC | 1.2 V | 160 | 23.5 x 15.4 | 5.4 | 5.8 | 16 | 4.8~8.0 |
 | H100BC | 1.2 V | 110 | 15.3 | 8 | 4.4 | 11 | 3.3~5.5 |
 | H60BC | 1.2 V | 80 | 15.4 | 6.1 | 3.5 | 8 | 2.4~4.0 |
 | H30BC | 1.2 V | 40 | 11.8 | 5.3 | 1.8 | 4 | 1.2~2.0 |
 | H12BC | 1.2 V | 18 | 11.8 | 3.3 | 1.3 | 1.8 | 0.5~0.9 |
