充電電池

鋰離子電池18650

Lithium Ion Batteries- PANASONIC	Type	NOMINAL VOLTAGE	Nominal Capacity	Nominal Capacity	Diameter	Height (Max.)	Approx.Weight (g)
Lithium Ion Batteries- PANASONIC	Type	(V)	(min.)	(typical.)	(Max.)	Height (Max.)	Approx.Weight (g)
NCR18650	High Capacity Models (Ni System)	3.6 V	2750 mAh	2900 mAh	18.2 mm	65.1 mm	45.5 g
NCR18650A	High Capacity Models (Ni System)	3.6 V	2950 mAh	3070 mAh	18.2 mm	65.1 mm	46.5 g
NCR18650B	High Capacity Models (Ni System)	3.6 V	3250 mAh	3350 mAh	18.3 mm	65.1 mm	47.5 g
NCR18650F	High Capacity Models (Ni System)	3.6 V	2750 mAh	2900 mAh	18.2 mm	65.1 mm	45.5 g

Lithium Ion Batteries-SANYO	Type	NOMINAL VOLTAGE	Nominal Capacity	Nominal Capacity	Diameter	Height (Max.)	Approx.Weight (g)
Lithium Ion Batteries-SANYO	Type	(V)	(min.)	(typical.)	(Max.)	Height (Max.)	Approx.Weight (g)
UR18650A	General Purpose Models	3.6 V	2150 mAh	2250 mAh	18.1 mm	64.8 mm	43 g
UR18650E	High Drain Models	3.6 V	2050 mAh	2150 mAh	18.1 mm	64.8 mm	44.5 g
UR18650SA	High Drain Models	3.6 V	1250 mAh	1300 mAh	18.1 mm	64.8 mm	44.3 g
UR18650SAX	High Drain Models	3.6 V	1250 mAh	1350 mAh	18.1 mm	64.8 mm	45 g
UR18650U	Long Life Models	3.6 V	1100 mAh	1200 mAh	18.1 mm	64.8 mm	41.5 g
UR18650W	High Drain Models	3.7 V	1500 mAh	1600 mAh	18.1 mm	64.8 mm	43.3 g
UR18650WX	High Drain Models	3.7 V	1500 mAh	1600 mAh	18.1 mm	64.8 mm	46.5 g
UR18650Y	General Purpose Models	3.7 V	1900 mAh	2000 mAh	18.1 mm	64.8 mm	43.3 g
UR18650ZT	High Capacity Models (High Charge Voltage)	3.7 V	2700 mAh	2800 mAh	18.2 mm	65.1 mm	48 g
UR18650ZTA	High Capacity Models (High Charge Voltage)	3.7 V	2900 mAh	3000 mAh	18.2 mm	65.1 mm	48 g
UR18650ZY	General Purpose Models	3.7 V	2500 mAh	2600 mAh	18.2 mm	64.8 mm	43.3 g

Lithium Ion Batteries-SANYO	Type	NOMINAL VOLTAGE	Nominal Capacity	Nominal Capacity	Diameter	Width (Max.)	Height (Max.)	Approx.Weight (g)
Lithium Ion Batteries-SANYO	Type	(V)	(min.)	(typical.)	(Max.)	Width (Max.)	Height (Max.)	Approx.Weight (g)
CGA362241	General Purpose	3.6 V	225 mAh	250 mAh	3.6 mm	21.6 mm	40.25 mm	7 g
CGA573442	General Purpose	3.7 V	930 mAh	960 mAh	5.6 mm	33.8 mm	41.56 mm	18.5 g
CGA573536A	General Purpose	3.6 V	750 mAh	785 mAh	5.68 mm	34.6 mm	35.5 mm	16.2 g
CGA632750	General Purpose	3.6 V	890 mAh	930 mAh	6.5 mm	27.1 mm	50.25 mm	19.5 g
CGA633438	General Purpose	3.7 V	950 mAh	980 mAh	6.4 mm	33.8 mm	38.05 mm	18.8 g
CGA633850	General Purpose	3.6 V	1350 mAh	1390 mAh	6.5 mm	38.1 mm	49.85 mm	30 g

Lithium Ion Batteries-SANYO	Type	NOMINAL VOLTAGE	Nominal Capacity	Nominal Capacity	Diameter	Width (Max.)	Height (Max.)	Approx.Weight (g)
Lithium Ion Batteries-SANYO	Type	(V)	(min.)	(typical.)	(Max.)	Width (Max.)	Height (Max.)	Approx.Weight (g)
UF103450P	General Purpose	3.7 V	1880 mAh	2000 mAh	10.5 mm	33.8 mm	48.8mm	38.5 g
UF383551FU	General Purpose	3.7 V	820 mAh	850 mAh	3.85 mm	34.95mm	50.55 mm	16.3 g
UF384461SU	General Purpose	3.7 V	1230 mAh	1280 mAh	3.8 mm	43.55 mm	60.7 mm	24.6 g
UF384961S	General Purpose	3.7 V	1400 mAh	1450 mAh	3.8 mm	48.8 mm	61 mm	27.5 g
UF463443GU	General Purpose	3.7 V	820 mAh	850 mAh	4.55 mm	33.85 mm	42.6 mm	16 g
UF463450F	General Purpose	3.7 V	920 mAh	960 mAh	4.55 mm	33.85 mm	49.6 mm	18.5 g
UF464462F	General Purpose	3.8 V	1460 mAh	1520 mAh	4.5 mm	43.6 mm	61.4 mm	29.1 g
UF464462FT	High Capacity (High Charge Voltage)	3.7 V	1520 mAh	1580 mAh	4.4 mm	43.6 mm	61.4 mm	28.4 g
UF484462S	General Purpose	3.7 V	1530 mAh	1590 mAh	4.7 mm	43.9 mm	61.7 mm	30.3 g
UF484462ST	High Capacity (High Charge Voltage)	3.8 V	1660 mAh	1710 mAh	4.7 mm	43.9 mm	61.7 mm	30 g
UF485155S	General Purpose	3.7 V	1660 mAh	1710 mAh	4.75 mm	50.9 mm	55 mm	31.9 g
UF495252ST	High Capacity (High Charge Voltage)	3.8 V	1660 mAh	1720 mAh	4.85 mm	51.9 mm	51.5 mm	30.3 g
UF495255S	General Purpose	3.7 V	1700 mAh	1760 mAh	4.9 mm	51.9 mm	55 mm	33.1 g
UF495255ST	High Capacity (High Charge Voltage)	3.8 V	1800 mAh	1870 mAh	4.85 mm	51.9 mm	55 mm	32.3 g
UF504553FU	General Purpose	3.7 V	1460 mAh	1510 mAh	5 mm	44.9 mm	52.6 mm	28.6 g
UF514657F	General Purpose	3.7 V	1670 mAh	1730 mAh	5.05 mm	46.1 mm	56.5 mm	31.4 g
UF515148ST	High Capacity (High Charge Voltage)	3.8 V	1600 mAh	1660 mAh	5.05 mm	50.9 mm	47.5 mm	28.7 g
UF534553F	General Purpose	3.7 V	1520 mAh	1580 mAh	5.25 mm	44.85 mm	52.5 mm	29.9 g
UF534553FT	High Capacity (High Charge Voltage)	3.8 V	1620 mAh	1680 mAh	5.25 mm	44.85 mm	52.5 mm	29.3 g
UF553436G	General Purpose	3.7 V	800 mAh	830 mAh	5.5 mm	33.85 mm	35.6 mm	15.6 g
UF553443ZU	General Purpose	3.7 V	1000 mAh	1040 mAh	5.55 mm	33.86 mm	42.8 mm	18.7 g
UF553450Z	General Purpose	3.7 V	1150 mAh	1200 mAh	5.55 mm	33.85 mm	49.8 mm	22.3 g
UF553939S	General Purpose	3.7 V	1010 mAh	1050 mAh	5.52 mm	38.9 mm	38.4 mm	19.4 g
UF564447F	General Purpose	3.7 V	1370 mAh	1420 mAh	5.55 mm	43.9 mm	46.6 mm	27 g
UF583136R	General Purpose	3.7 V	700 mAh	740 mAh	5.6 mm	31.15 mm	36.3 mm	14.2 g
UF624447F	General Purpose	3.7 V	1520 mAh	1580 mAh	6.15 mm	43.9 mm	46.6 mm	29.9 g
UF653039SU	General Purpose	3.7 V	920 mAh	960 mAh	6.4 mm	29.95 mm	38.75 mm	17.5 g
UF653436SU	General Purpose	3.7 V	900 mAh	930 mAh	6.3 mm	33.85 mm	35.7 mm	17.8 g
UF653445ST	High Capacity (High Charge Voltage)	3.8 V	1220 mAh	1260 mAh	6.3 mm	44.5 mm	33.8 mm	22.3 g
UF653450S	General Purpose	3.7 V	1250 mAh	1300 mAh	6.35 mm	33.85 mm	49.8 mm	25.1 g
UF703141FU	General Purpose	3.7 V	1050 mAh	1090 mAh	7.05 mm	30.5 mm	40.7 mm	20.9 g
UF703450F	General Purpose	3.7 V	1430 mAh	1480 mAh	7 mm	33.85 mm	49.8 mm	28.1 g
UF752836F	General Purpose	3.7 V	850 mAh	890 mAh	7.5 mm	27.95 mm	35.8 mm	17.3 g
